For professional audio-visual installers, the problem that is often found is the unsynchronization of the signal source and the display screen, resulting in problems such as no picture or flickering picture. This tool can help you to quickly analyze compatibility issues at the installation location.
The XA-4 Advanced HDMI Pattern Generator and Analyzer is an integrator tool for generating 4K HDMI signals to verify and test a wider range of AV installations. The device has 54 resolution settings, 47 test patterns and 6 analytical tests providing over 1000 different test scenario combinations.
t also supports HDMI data packets, EDID & HDCP analysis, EDID emulation, and allows users to store 2 custom patterns, along with the ability to output up to 8 channels of audio.
The front panel buttons enable quick support between various functions and the OLED display supports quick display of current status information. Control is done via front panel buttons, IR, RS-232, and Telnet which allows you to have full flexibility in controlling the device.
In addition, this tool also supports HD resolutions up to 4096x2160 @60Hz (4:4:4, 8-bit), SCDC (Status and Control Data Channel) Detection can accurately detect the quality of HDMI video and audio signals, HDMI 2.0 cable test includes testing for 5V, CEC and hot-plug detection support, last but not least, the size of the tool is compact so it can be operated with one hand with a rechargeable Lithium-ion battery.
For more detailed specifications regarding the XA-4 Advanced HDMI Pattern Generator and Analyzer, you can check here. And don't forget to check other products from CYP, TE-ners! http://en.cypress.com.tw
